Standard Connectors rated to 350ºC

R13 Standard High Temperature Plug

  • Thermosetting plastic body rated to 350ºC
  • Available for thermocouple types: K, T, J, N, R/S, E, B and Cu
  • Coloured brown and thermocouple type indicated on body
  • Easy wiring via lipped washer
  • Accepts stranded or solid wires up to 0.2mm to 1.29mm diameter (0.03mm² to 1.3mm²). With washer removed: up to 1.63mm diameter (2.1mm²).
  • Manufactured in accordance with standard EN 50212
  • High purity thermocouple alloys used for male pin and female socket constructions
  • Polarised round pins with mechanism to prevent accidental output
  • Single captive screw for quick assembly

Related Connectors

Standard High Temp
Plug - Quick Wire
Part Code: R08
Standard High Temp
Socket
Part Code: R22
Standard High Temp
Socket - Quick Wire
Part Code: R09
Standard High Temp
Plug - Three Pin
Part Code: R18

Enquiry Form

R13 Thermocouple Type


Colour Code


Quantity Required


R08 Thermocouple Type


Colour Code


Quantity Required


R22 Thermocouple Type


Colour Code


Quantity Required


R09 Thermocouple Type


Colour Code


Quantity Required


R18 Thermocouple Type


Colour Code


Quantity Required


Contact Details


Company Name


Your Name


Title/Dept.


Email


Telephone


Additional Information


If your enquiry is for more than one style of connector, please email us with your requirements or use the box below



Send Enquiry

We will only use your email address to contact you. We will never give your email address to 3rd parties and we do not sell data on to any other company. We prefer to concentrate on making quality temperature related products.

1 Thermocouple Type Temperature Range (continuous) Temperature Range
(short term)
K Nickel Chromium vs
Nickel Aluminium
0°C to +1100°C -180°C to +1350°C
T Copper vs Constantan -185°C to +300°C -250°C to +400°C
J Iron vs Constantan +20°C to +700°C -180°C to +750°C
N Nicrosil vs Nisil 0°C to +1100°C -270°C to +1300°C
E Nickel Chromium vs Constantan 0°C to +800°C -40°C to +900°C
R Platinum - 13% Rhodium vs
Platinum
0°C to +1600°C -50°C to +1700°C
S Platinum - 10% Rhodium vs
Platinum
0°C to +1550°C -50°C to +1750°C
B Platinum - 30% Rhodium vs
Platinum 6% Rhodium
+100°C to +1600°C +100°C to +1820°C
Temperature ranges refer to the operating range of the thermocouple type.
The temperature range of the connector will be as stated.
Please refer to the product description for more details.
