ATEX Approved Pressure and Vacuum Feedthroughs

Series WF - Feedthroughs for multiple wires and probes

When multiple wires must pass through a pressure boundary, series WF feedthroughs can provide an efficient seal without recourse to epoxies or other non-adjustable fixture methods.

Different types of these assemblies may be specified according to the type of element required to pass through the feedthrough. Series WF assemblies cater for up to 12 bare or insulated wires – sizes from 24AWG (0.2mm2) to 8AWG (approx. 8.8mm2).

Insulators within WF feedthrough assemblies protect bare wires and provide additional isolation for Kapton® insulated power wires. These are rated 55A @ 600Vdc/850Vac max. Feedthroughs with power wires can be supplied as complete assemblies, ready for installation, with wires cut to specified lengths.

WF feedthroughs can also accommodate up to 12, small diameter sensor elements that must be electrically isolated from each other.
  • ATEX Approved to Ex II 2 GD, Ex d IIC Gb / Ex e IIC Gb, Ex ta IIIC Da
  • Seal on Kapton® insulated copper or thermocouple wires – type WFS
  • Seal on bare wires carrying instrumentation voltages – type WFR
  • Seal on small diameter sheathed sensors, max. 3.2mm dia. – type WFP
  • Pressure range: Vacuum to 700 bar*
  • Temperature range: -60°C to +200°C*
  • 316L Body (and seat where applicable). Follower and cap in 303 or 304
  • Choice of 3 sealant materials
  • Individual wires can be replaced without complete disassembly
  • Reusable fitting – sealant and internal components replaceable
  • * Dependent on sealant and fitting selected

Enquiry Form

1. Feedthrough Type

2. Thread Size Required

  see table
3. Element Size

 see table
4. No. of Elements

 see table
5. Sealant Type

 see table
6. Quantity Required

Contact Details

Company Name


Your Name


Email


Telephone


Additional Information

If your enquiry is for more than one style of sensor, please email us with your requirements or use the box below



Send Enquiry
