Miniature Thermocouple Plug - Three Pin - F16
Miniature Thermocouple Connectors rated to 220ºC
IEC Colours | ANSI Colours | ||||
---|---|---|---|---|---|
Part No. | Type | Colour | Part No. | Type | Colour |
F16K-I | K | F16K-A | K | ||
F16T-I | T | F16T-A | T | ||
F16J-I | J | F16J-A | J | ||
F16N-I | N | F16N-A | N | ||
F16RS-I | R/S | F16RS-A | R/S | ||
F16E-I | E | F16E-A | E | ||
F16B-I | B | F16B-A | B | ||
F16CU | Cu | F16CU | Cu |
- Thermoplastic body rated to 220ºC
- Available for thermocouple types: K, T, J, N, R/S, E, B and Cu (for RTD's)
- Body colour coded and thermocouple type indicated on body
- Easy wiring via lipped washer
- Accepts stranded or solid wires up to 0.8mm diameter (0.5mm²)
- Manufactured in accordance with standard EN 50212
- High purity thermocouple alloys used for male pin and female socket constructions
- Bevel tipped pins for easy insertion
- Polarised flat pins
