Miniature Thermocouple Socket - Three Pin - F25

Miniature Thermocouple Connectors rated to 220ºC

  • Thermoplastic body rated to 220ºC
  • Available for thermocouple types: K, T, J, N, R/S, E, B and Cu (for RTD's)
  • Body colour coded and thermocouple type indicated on body
  • Easy wiring via lipped washer
  • Accepts stranded or solid wires up to 0.8mm diameter (0.5mm²)
  • Manufactured in accordance with standard EN 50212
  • High purity thermocouple alloys used for male pin and female socket constructions
  • Bevel tipped pins for easy insertion
  • Polarised flat pins
