Pipe Thermocouple, Adjustable Ring - in line to pipe (Type 7B)

General Purpose Thermocouples

Related Products

Miniature Socket

Related Products

Standard Socket
These adjustable ring sensors are for pipe temperature measurement up to 600°C. Available in thermocouple types K, T, J, N and E. Type 7B Ring thermocouples are made with a mineral insulated thermocouple and can be supplied with insulated or grounded junctions. Normally supplied with stainless steel conduit over PFA extension leads, although other lead options are available. Ring in line to pipe.

Adjustable Ring Thermocouple Enquiry Form

1. Thermocouple Type
2. Diameter Required (pipe)

3. Cable Length

 mtrs
4. Types of Sensing Junction

Illustration Select
GROUNDED Junction
INSULATED Junction
Duplex Element Required? (please tick box)
5. Optional Thermocouple Plug

6. Quantity Required

Contact Details

Company Name


Your Name


Title/Dept.


Email


Telephone


Additional Information

If your enquiry is for more than one style of sensor, please email us with your requirements or use the box below



Send Enquiry

We will only use your email address to contact you. We will never give your email address to 3rd parties and we do not sell data on to any other company. We prefer to concentrate on making quality temperature related products. Our privacy policy can be viewed here.
1 Thermocouple Type Temperature Range (continuous) Temperature Range
(short term)
K Nickel Chromium vs
Nickel Aluminium
0°C to +1100°C -180°C to +1350°C
T Copper vs Constantan -185°C to +300°C -250°C to +400°C
J Iron vs Constantan +20°C to +700°C -180°C to +750°C
N Nicrosil vs Nisil 0°C to +1100°C -270°C to +1300°C
E Nickel Chromium vs Constantan 0°C to +800°C -40°C to +900°C
Temperature ranges refer to the thermocouple type.
The temperature range of the sensor may deviate from the above,
please refer to the product description for more details

INSULATED
Hot junction insulated from sheath. Gives floating output with typical insulation resistance in excess of 100 megohms

GROUNDED
Hot junction welded to sheath tip giving earthed output and faster response to temperature changes
